Switchboard Mats and Anti Static Matting

For under electrical panels, fuse boxes,
transformers and near high voltage electrical apparatus.

Corrugated Switchboard Mats | Mil Spec Smooth Top | Information Sheet
Diamond Switchboard Matting-Anti-Static Mats | Rubber Mats | Tel. 1-661-273-8700
switchboard mat
A Power Panel Stores/Produces More than 50,000 Volts Alternating Current (VAC). High Voltage Switchboard Mats Saves Life's.

CWF Flooring, Inc. produces all types of switchboard mats, anti-static mats for dielectric, anti-static areas. Meets Mil Specs, ASTMD-178, OSHA for electrical switchboard matting. Insulating switchboard matting is tested with accurate military and commercial technical data and values. All electrical safety mats can be used in a high voltage environment. CWF Flooring, Inc. matting will guard employees and staff against accidental electrical and static shock. In addition, our quality anti-static mats and switchboard matting shields electrical equipment from electrostatics.

For more information call our sales department: 1-661-273-8700 or 1-661-273-8701

Corrugated & Diamond Switchboard Matting - ASTMD-178
Whatís the difference between Switchboard Mats and Anti Static Mats?
Switchboard matting is designed to protect people from high voltage. Vinyl switchboard mats will insulate workers from the dangers of electrical equipment.
Whereas, anti static mats protects electrical components and equipment from electrostatics that can damage sensitive electrical equipment and cause breakage and/or effect the performance of calibrations.
In a nut shell, Switchboard mats protects people anti static matting shields electrical equipment.

3

2

vac

Black Switchboard Matting
Alternating High Voltage Corrugated Mats Are Produced in 2, 3, or 4 Feet Wide Widths

Corrugated Switchboard Matting and Anti-Static Mats

SB4361/4" Thick, Type II, Class 2 Switchboard Corrugated Switchboard Mats
Have a DIELECTRIC TEST VOLTAGE of 30,000 VAC
Diamond & Corrugated high voltage mats-can be used as an anti static mat- are non-conductive, compounded and corrugated mat with a diamond texture for use in high voltage, fuse box and high static work areas.

Diamond switchboard mat rolls conform to the Occupational Safety and Health Administration requirements for electrical machinery and meets ASTMD-178.
Said requirements via safety data is met via the entire mat surface. In addition, our Corrugated & Diamond Switchboard Matting is flame, oil and ozone resistance.

corrugated anti-static mat

The yellow safety boarder is an option on our high voltage switchboard mats. As well the yellow border will add an industrial appearance and broadcast to workers that safety is a priority with your company.

corrugated switchboard matting20000 volt mat
  • A specialty compounded non-conductive corrugated matting designed to help prevent electric shock around high voltage electrical equipment, such as fuse boxes, and control panels.
  • Now meets all optional requirements for Ozone resistance, Flame Resistance, and Oil Resistance.
  • Tested to ASTM D/178/ANSI J6.7 Certification engraved on back.
  • A high quality switchboard mat.
  • Anti static as well.
  • Corrugated Switchboard Matting Info Sheet
Corrugated high voltage floor mats will provide anti-slip feature for a business that canít afford slips. With this added feature, your dielectric mat and be dual purposed; an anti-slip mat and an electrical safety mat.
Type II Class 1 Mat
Corrugated Switchboard Mat Rolls

3/16" Thick - Type II, Class 1 Switchboard Mats
Dielectric Mat Test Voltage: 22.000 VAC
Proof tested entire surface at 10.000 VAC
Rec. Max. use voltage: 7.500 VAC
Mat Color: Black
Size Weight Ea

Price Roll

3´ x 75´ 3.9 lbs. $910


Quantity :
Size :

1/4" Thick - Type II, Class 2 Switchboard Mats
Dielectric Test Voltage: 30.000 VAC
Proof tested entire surface at20.000 VAC
Rec. Max. use voltage: 17.000 VAC
Color: Solid Black (3' & 4' only)
Size Weight Ea

Price Per Roll

2´ x 75´ 3.5 lbs. $760
3´ x 75´ 5.2 lbs. $994
4´ x 75´ 6.8 lbs. $1885
Size Weight Ea

Price Per Linear Foot

2´ x 75´ 3.5 lbs. $14.56
3´ x 75´ 5.2 lbs. $19.56
4´ x 75´ 6.8 lbs. $34.56


Quantity :
Size :

3/8" Thick - Type II, Class 3 Switchboard Mats
Dielectric Mat Test Voltage: 40.000 VAC
Proof tested entire surface at 30.000 VAC
Rec. Max. use voltage: 26.500 VAC
Color: Black
Size Weight Ea

Price Roll

3´ x 45´ 7.7 lbs. $2020


Quantity :
Size :


1/2" Thick - Type II, Class 4 Switchboard Mats
Dielectric Mat Test Voltage: 50.000 VAC
Proof tested entire surface at 40.000 VAC
Rec. Max. use voltage: 36.000 VAC
Color: Black
Size Weight Ea

Price Roll

3´ x 30´ 10.7 lbs. $1774


Quantity :
Size :

For more information call the Sales Dept. 1-661-273-8700 or 1-661-273-8701



smooth anti-static mat
Smooth Textured Mat Rolls For High Voltage Areas are Produced Up to 75 Feet Long

Mil Spec Smooth Top Switchboard Mats and Anti-Static Mats

aa⅛″ Smooth Switchboard Mats Conforms to MIL SPEC. MIL-DTL-155626, Type II
High voltage mat tops are smooth. Under surface is textured for sure non-slip floating.

Mat applications are for avionics, marine, commercial and industrial to protect workers in a high voltage area such as work benches, distribution boards or switch gears and can provide anti static protection for electrical equipment.

smooth electrical mat
Conforms to MIL SPEC, MIL-DTL-15562G, Type II Mil Spec Smooth Top Switchboard Mats
  • Conforms to MIL SPEC, MIL-DTL-15562G, Type II.
  • This specification is approved for use by all interested commands of the department of the Navy and the Marine Corps and is available for use by all other Departments and Agencies of the department of Defense.
  • Mil Spec Smooth Top Switchboard Mats Info Sheet
1/8" Thick - TMil. Spec. Mil-DTL-15562G, Type II
Dielectric Test Voltage: 30.000 VAC
Proof tested entire surface at 15.000 VAC
Rec. Max. use voltage: 3.000 VAC
Color: Black, Blue, Green
Size Weight Ea

Price Roll

3´ x 75´ 245 lbs. $793


Quantity :
Size :
Color :

A company that fails to meet OSAH Electrical Safety guidelines will face serious legal consequences complicated with civil law suits by employees. Improper usage of electrical safety mats could lead to serious injury or death.
Itís is crucial that electrical safety mats are used when working near switchboards, electrical panels, and all electrical machinery.


diamond plate switchboard mat

Diamond Switchboard Mats and Anti-Static Mats

rhino matsDiamond Texture Will Add Anti-slip Features & An Industrial Appearance. Diamond Switchboards Are Available up to 75 Feet.

These anti-static mat rolls are used by the DOD as well as commercial and industrial uses. Handsome deck plates have a diamond surface. Resistant to sulphuric acid, O-Bomb aging as well as UV rays.
For more information call our sales department: 1-661-273-8700 or 1-661-273-8701
Non-conductive-mats diamond switch board mats
  • Conforms to MIL SPEC, MIL-DTL-15562G, Type III.
  • Conductive and Static Dissipative, Anti static
  • This specification is approved for use by all interested commands of the department of the Navy and the Marine Corps and is available for use by all other Departments and Agencies of the department of Defense.
  • Diamond Texture Switchboard Mat Info Sheet
3/16" Thick - TMil. Spec. Mil-DTL-15562G, Type III
Dielectric Test Voltage: 30.000 VAC
Proof tested entire surface at 15.000 VAC
Rec. Max. use voltage: 3.000 VAC
Color: Gray
Size Weight Ea

Price Roll

3´ x 75´ 252 lbs. $1612


Quantity :
Size :




Fuse box Safety Mat

Safety Mat For Fusebox
  • Fuse box safety mats is a staple for residential or commercial electricians who are repair/replace breakers, circuit parts for fuses.
  • Class 2 specification, ASTM D178, up to 17KV. A sponge base with a laminated cover will provide anti-fatigue and non-conductive properties.
  • Fuse box Safety Mats are manufactured for personal protective equipment and comfort, they should only be used to offer “temporary” electrical insulation for energized equipment.
  • CWF fuse box safety mats must be used in conjunction with engineering safeguards and should not be used solely against electrician hazards.
  • Overall size 16 × 18 x 5/8"
5/8" Thick -Class 2 specification,
ASTM D178, up to 17KV
Color: BLACK
Size Weight Ea

Price Roll

16" x 18" 17 lbs. $49.55


Quantity :
Size :


About: Non-conductive-mats & High Voltage Mats

Switchboard Mats for under fuse boxes, transformers and around high voltage electrical apparatus.

electricial floor mat
Residential Electricians Are Required to Use Electrical Floor Mats
Occupational Safety & Health Administration Stats

According to OSHA electrocutions are in the top four of fatal work related accidents. The rank is as follows:

  1. Falls – 264 out of 774 total deaths in construction in CY 2010 (34%)
  2. Electrocutions – 76 (10%)
  3. Struck by Object – 64 (8%)
  4. Caught-in/between – 33 (4%)
Protect your workers and employees with
CWF Flooring, Inc. anti static & switchboard mats!
Source: www.osha.gov/oshstats/commonstats.html
